Fractional size
| Tube OD |
P-NPT Size |
Catalog Number |
L |
E |
F |
1/8
|
1/8
1/4 |
-FA-02F-02N
-FA-02F-04N
|
1.24
1.39
|
0.08 |
9/16
3/4 |
3/16
|
1/4 |
-FA-03F-04N
|
1.41 |
0.12 |
3/4
|
1/4
|
1/8
1/4
3/8
1/2 |
-FA-04F-02N
-FA-04F-04N
-FA-04F-06N
-FA-04F-08N
|
1.30
1.46
1.55
1.79 |
0.17 |
9/16
3/4
7/8
1 1/16 |
5/16
|
1/4
|
-FA-05F-04N
|
1.48 |
0.22 |
3/4 |
3/8
|
1/8
1/4
3/8
1/2 |
-FA-06F-02N
-FA-06F-04N
-FA-06F-06N
-FA-06F-08N
|
1.35
1.50
1.59
1.84 |
0.27 |
9/16
3/4
7/8
1 1/16 |
1/2
|
1/4
3/8
1/2 |
-FA-08F-04N
-FA-08F-06N
-FA-08F-08N
|
1.71
1.79
2.05 |
0.37 |
3/4
7/8
1 1/16 |
5/8
|
1/2
|
-FA-10F-08N
|
2.09 |
0.47 |
1 1/16 |
3/4
|
1/2
3/4
1 |
-FA-12F-08N
-FA-12F-12N
-FA-12F-16N
|
2.08
2.16
2.30 |
0.58 |
1 1/16
1 5/16
1 5/8 |
1
|
3/4
1
|
-FA-16F-12N
-FA-16F-16N
|
2.39
2.53 |
0.80 |
1 5/16
1 5/8 |
Dimensions are for reference and subject to change. |
|
|
|
Metric size
| Tube OD |
P-NPT Size |
Catalog Number |
L |
E |
F |
| 6 |
1/8
1/4 |
-FA-06M-02N
-FA-06M-04N
|
32.5
37.1 |
4.1 |
14
19 |
| 8 |
1/4
|
-FA-08M-04N
|
37.6 |
5.6 |
19 |
| 10 |
1/4
3/8
1/2 |
-FA-10M-04N
-FA-10M-06N
-FA-10M-08N
|
38.1
40.1
46.7 |
7.1 |
19
22
27 |
| 12 |
1/4
1/2 |
-FA-12M-04N
-FA-12M-08N
|
43.7
52.3 |
8.8 |
19
27 |
Dimensions are for reference and subject to change. |
