Fractional size
| Tube OD |
P-NPT Size |
Catalog Number |
L |
B |
E |
F (in.) |
H |
1/8
|
1/8
1/4
|
-MBT-02F-02N
-MBT-02F-04N
|
1.86
1.94 |
0.50 |
0.09 |
7/16
1/2 |
0.70
0.92 |
3/16
|
1/8
|
-MBT-03F-02N
|
1.92 |
0.54 |
0.12 |
7/16 |
0.70 |
1/4
|
1/8
1/4 |
-MBT-04F-02N
-MBT-04F-04N
|
2.12 |
0.60 |
0.19 |
1/2 |
0.74
0.92 |
5/16
|
1/8
|
-MBT-05F-02N
|
2.34 |
0.64 |
0.19 |
5/8 |
0.82 |
3/8
|
1/4
3/8
|
-MBT-06F-02N
-MBT-06F-06N
|
2.40
2.62 |
0.66 |
0.28 |
5/8
13/16 |
1.00
1.11 |
1/2
|
3/8
1/2
|
-MBT-08F-06N
-MBT-08F-08N
|
2.84 |
0.90 |
0.38
0.41 |
13/16 |
1.11
1.30 |
5/8
|
1/2
|
-MBT-10F-08N
|
3.06 |
0.96 |
0.47 |
1 |
1.41 |
3/4
|
3/4
|
-MBT-12F-12N
|
3.14 |
0.96 |
0.62 |
1 1/16 |
1.45 |
Dimensions are for reference and subject to change.
|
|
|
|
Metric size
| Tube OD |
P-NPT Size |
Catalog Number |
L |
B |
E |
F(in.) |
H |
6
|
1/8
1/4 |
-MBT-06M-02N
-MBT-06M-04N
|
53.9 |
15.3 |
4.8 |
1/2 |
18.8
23.4 |
| 8 |
1/8
1/4
|
-MBT-08M-02N
-MBT-08M-04N |
59.7 |
16.2 |
4.8
6.4 |
5/8 |
20.8
25.4 |
| 10 |
1/4
|
-MBT-10M-04N
-MBT-10M-04N
|
67.0 |
17.2 |
7.1 |
13/16 |
26.2 |
| 12 |
3/8
1/4
1/2 |
-MBT-12M-06N
-MBT-12M-04N
-MBT-12M-08N |
72.0 |
22.8 |
9.5
7.1
9.5 |
13/16 |
28.2
28.2
33.0 |
| 16 |
1/2 |
-MBT-16M-08N |
77.6 |
24.4 |
11.9 |
1 |
35.8 |
Dimensions are for reference and subject to change.
|
